Multi functional electric bed

Product Introduction:

• Powerful in function, suitable for hospital ICU intensive care units, neurosurgery, minimally invasive surgery, thoracic surgery, general surgery, vascular surgery, urology, orthopedics, respiratory medicine, gastroenterology, obstetrics and other departments.

Product Features：

1. One click electronic CPR button--can quickly return to the lowest flat state in any posture using the bed, making it convenient for rescuing patients.

2. Panel locking function--Prevent patients with unclear consciousness and manic state from accidentally touching the operation panel, causing medical risks

3. Applicable to intracranial hypertension, brain injury, acute obstructive suppurative cholangitis, acute pancreatitis, pancreatic cancer, periampullary cancer; Patients with conditions such as Cushing's syndrome, pyogenic osteomyelitis, pyogenic arthritis, streptococcal inflammation, poisoning, and gestational hypertension may experience confusion, restlessness, and other symptoms

4. Applied to ICU, general surgery, neurosurgery, hepatobiliary surgery, urology, orthopedics, respiratory medicine, infectious diseases, obstetrics and other hospital departments.

5. Back leg linkage--One click implementation of concave position (shock position), semi sitting position, and cardiac chair position

6. Automatic angle adjustment, angle range: 0-65 degrees for the back and 0-40 degrees for the legs


7. This function is widely used in the treatment and nursing of diseases in the following departments, and has a positive auxiliary therapeutic significance.

Technical specifications:

• Bed size：2240*1050*500-750mm

• Bed surface size：1940*900mm

• Back angle：0-65度

• Leg angle：0-40度

• Height range of bed panel：500-750mm

• Tet position/inverse Tet position: 0-12 degrees

• Additional features: electronic CPR, keyboard lock, electronic brake, soft connection, touch keyboard * 5, backup battery 12V 1.3AH * 2, quick release headboard

• Maximum static load：250KG

• Suggested patient weight：≤175KG

• Guardrail load-bearing capacity：50KG

• Salt water rack load-bearing capacity：10KG

• Suggested usage period: 5 years

• Net weight：148KG

Packing list:

1. Bed *1

2. Headboard*1

3. Bed tail board*1

4. Saltwater rack*1

5. instructions*1
